Neutron Imaging, an Essential Tool for the Hydrogen Economy

The problem that the NIST Neutron Imaging Facility (NIF) can address that directly impacts the progress of the Hydrogen Economy is the issue of flooding and water management in hydrogen fuel cells. The development of robust and efficient fuel cell designs requires a non-destructive tool that can probe and evaluate the production of water in hydrogen powered fuel cells. Here at the NIST Center for Neutron Research a new, advanced fuel cell imaging facility has been built to do just this. This facility provides the necessary infrastructure for fuel cell manufacturers and university users to perform fuel cell experiments on both commercial grade and smaller research grade fuel cells and stacks. This facility allows visualization of water production and removal in operating fuel cells in conditions simulating the real world artic freeze/thaw and desert heat environments. The current NIF is a second generation of neutron imaging facilities built here at NIST. This capability has recently received independent credit for the impact it is providing to fuel cell developers from the National Academies report, which states that: "The NIST effort ... is a considerable achievement and one of the most significant analytical advances in the membrane fuel cell realm in decades. The NIST facility offers the entire fuel cell community unique research opportunities that previously eluded them."

Most recently this capability at NIST has been highlighted in this excerpt from the President's American Competitiveness Initiative:

  Photo of single fuel cell.

Caption: A typical fuel cell is shown on top and below is the neutron image of water formed inside during operation.

Neutron image of water formed inside fuel cell during operation, thickness represented by color

NIST PEMFC movie

NIST PEMFC movie 3.8 MB
To play this movie you may need to "right click" and save the movie to your computer.

[Get a free Media Player]


Overcoming Technological Barriers to the Hydrogen Economy The "hydrogen economy" would use domestic sources of energy to create hydrogen gas, which in turn could be used as a transportation fuel. Other possibilities include using hydrogen-bearing fuels such as alcohol or natural gas as potentially economical and long-lasting sources of electrical power for portable electronics such as cell phones and laptop computers, or even for powering buildings that are remote from power lines.

Many technical and economic hurdles remain before these technologies can be made widely available. Reducing costs, improving efficiencies, and making the technology reliable enough for everyday use will all be important. If these technical goals are achieved, the broad use of hydrogen as a fuel may prove to have environmental advantages as well. The Department of Energy is leading the Presidentís Hydrogen Fuel Initiative to achieve these goals.

NIST research helps support this developing technology in many ways. Projects currently under way at NIST are providing measurements, data, and technologies needed to develop and test the performance of hydrogen-based power sources and to improve the efficiency of hydrogen production methods.

Muhammad Arif working on fuel cell testing equipment at the Neutron Imaging Facility
  © Robert Rathe
A new imaging facility at the NIST Center for Neutron Research provides a rare portal for visualizing water and hydrogen transport in fuel cells. Neutrons reveal how water forms and moves while a fuel cell is operating. Mastering the combined challenge of managing incoming humidity, proper hydration of fuel cell membranes, and the handling of water byproducts is essential to the development of fuel cells that are practical for automotive and residential applications as well as portable devices.
