Gafchromic Sensor
HTML table format
|
|
| Energy |
|
 |
|
 |
| (MeV) |
(cm2/g) |
(cm2/g) |
|
| 1.00000E-03 |
2.594E+03 |
2.589E+03 |
| 1.50000E-03 |
8.437E+02 |
8.419E+02 |
| 2.00000E-03 |
3.705E+02 |
3.693E+02 |
| 3.00000E-03 |
1.129E+02 |
1.120E+02 |
| 4.00000E-03 |
4.776E+01 |
4.713E+01 |
| 5.00000E-03 |
2.436E+01 |
2.384E+01 |
| 6.00000E-03 |
1.402E+01 |
1.357E+01 |
| 8.00000E-03 |
5.892E+00 |
5.523E+00 |
| 1.00000E-02 |
3.052E+00 |
2.728E+00 |
| 1.50000E-02 |
1.014E+00 |
7.481E-01 |
| 2.00000E-02 |
5.366E-01 |
2.990E-01 |
| 3.00000E-02 |
2.943E-01 |
8.733E-02 |
| 4.00000E-02 |
2.322E-01 |
4.248E-02 |
| 5.00000E-02 |
2.066E-01 |
2.905E-02 |
| 6.00000E-02 |
1.925E-01 |
2.448E-02 |
| 8.00000E-02 |
1.759E-01 |
2.281E-02 |
| 1.00000E-01 |
1.651E-01 |
2.368E-02 |
| 1.50000E-01 |
1.467E-01 |
2.674E-02 |
| 2.00000E-01 |
1.339E-01 |
2.894E-02 |
| 3.00000E-01 |
1.161E-01 |
3.125E-02 |
| 4.00000E-01 |
1.039E-01 |
3.212E-02 |
| 5.00000E-01 |
9.487E-02 |
3.233E-02 |
| 6.00000E-01 |
8.772E-02 |
3.218E-02 |
| 8.00000E-01 |
7.704E-02 |
3.142E-02 |
| 1.00000E+00 |
6.926E-02 |
3.040E-02 |
| 1.25000E+00 |
6.194E-02 |
2.906E-02 |
| 1.50000E+00 |
5.637E-02 |
2.778E-02 |
| 2.00000E+00 |
4.835E-02 |
2.553E-02 |
| 3.00000E+00 |
3.872E-02 |
2.227E-02 |
| 4.00000E+00 |
3.308E-02 |
2.008E-02 |
| 5.00000E+00 |
2.935E-02 |
1.853E-02 |
| 6.00000E+00 |
2.672E-02 |
1.739E-02 |
| 8.00000E+00 |
2.324E-02 |
1.583E-02 |
| 1.00000E+01 |
2.108E-02 |
1.483E-02 |
| 1.50000E+01 |
1.815E-02 |
1.344E-02 |
| 2.00000E+01 |
1.675E-02 |
1.275E-02 |
|
|
Gafchromic Sensor
ASCII format
_________________________________
Energy
(MeV) (cm2/g) (cm2/g)
_________________________________
1.00000E-03 2.594E+03 2.589E+03
1.50000E-03 8.437E+02 8.419E+02
2.00000E-03 3.705E+02 3.693E+02
3.00000E-03 1.129E+02 1.120E+02
4.00000E-03 4.776E+01 4.713E+01
5.00000E-03 2.436E+01 2.384E+01
6.00000E-03 1.402E+01 1.357E+01
8.00000E-03 5.892E+00 5.523E+00
1.00000E-02 3.052E+00 2.728E+00
1.50000E-02 1.014E+00 7.481E-01
2.00000E-02 5.366E-01 2.990E-01
3.00000E-02 2.943E-01 8.733E-02
4.00000E-02 2.322E-01 4.248E-02
5.00000E-02 2.066E-01 2.905E-02
6.00000E-02 1.925E-01 2.448E-02
8.00000E-02 1.759E-01 2.281E-02
1.00000E-01 1.651E-01 2.368E-02
1.50000E-01 1.467E-01 2.674E-02
2.00000E-01 1.339E-01 2.894E-02
3.00000E-01 1.161E-01 3.125E-02
4.00000E-01 1.039E-01 3.212E-02
5.00000E-01 9.487E-02 3.233E-02
6.00000E-01 8.772E-02 3.218E-02
8.00000E-01 7.704E-02 3.142E-02
1.00000E+00 6.926E-02 3.040E-02
1.25000E+00 6.194E-02 2.906E-02
1.50000E+00 5.637E-02 2.778E-02
2.00000E+00 4.835E-02 2.553E-02
3.00000E+00 3.872E-02 2.227E-02
4.00000E+00 3.308E-02 2.008E-02
5.00000E+00 2.935E-02 1.853E-02
6.00000E+00 2.672E-02 1.739E-02
8.00000E+00 2.324E-02 1.583E-02
1.00000E+01 2.108E-02 1.483E-02
1.50000E+01 1.815E-02 1.344E-02
2.00000E+01 1.675E-02 1.275E-02
|
